1-1/4" Hayward DAB Series True Union CPVC Diaphragm Valve w/Socket and Threaded ends, EPDM O-rings

$435.99

Quick Overview

SKU: DAB2012UEE

1-1/4" Hayward DAB Series True Union CPVC Diaphragm Valve w/Socket and Threaded ends, EPDM O-rings
OR

Details

The DAB Series Diaphragm Valves are available in sizes 1/2 inch to 6 inch, with PVC, CPVC, PP and PVDF materials. Possible end connections are true-union socket or threaded and flanged ends. All DAB Series feature a highly visable beacon indicator. Possible diaphragm materials are EPDM, FPM and PTFE. PVDF vapor barrier available upon request for EPDM and PTFE diaphragms. The DAB Series are also available with pneumatic or electric actuation.

Additional Information

SKU DAB2012UEE
Manufacturer Hayward
Type Diaphragm Valve
Style True Union
Series DAB Series
Valve Type True Union Diaphragm Valve
Valve Size 1-1/4"
Valve Connection Type Socket and Threaded
Material CPVC
Seal Type Double O-Ring Stem
Seal Material EPDM
Diaphragm Material EPDM
Color Light Gray
Max Pressure 150 PSI (10.3 bar) @ 70˚F (21˚C)
Carton Qty 1
UPC Code 0610377087353
Installation Manual Hayward DAB2012UEE Installation Manual
Technical Data Hayward DAB2012UEE Technical Data
Dimensions Image Hayward DAB2012UEE Drawing
