1/2" Hayward SB Series CPVC Simplex Basket Strainer w/Socket/Threaded ends

$500.99

Quick Overview

SKU: SB2050STE

Strainer price includes the standard Stainless Steel perforated basket. If your application requires a mesh basket, please call customer service to get your updated price for the strainer / basket combo unit

OR

Details

When pipeline system components require protection from dirt and debris and the line can be shut down for basket cleaning, a Hayward All Plastic Simplex Basket Strainer is the ideal choice. Unwanted particles are removed as the process media passes through a perforated strainer basket contained inside the strainer body. The basket traps the unwanted material while allowing the process media to flow freely.

Available in sizes 1/2 inch to 4 inch in PVC, CPVC, GFPP Black, GFPP Platinum and Eastar® materials. Seals are FPM or EPDM with either socket, threaded or flanged end connections. Each strainer comes with a standard plastic basket. Other basket materials available such as SS316, Monel and Hastelloy available upon request. See Basket Replacements.

Additional Information

SKU SB2050STE
Manufacturer Hayward
Type Basket Strainer
Style Simplex
Series SB Series
Strainer Size 1/2"
Strainer Connection Type Socket/Threaded
Material CPVC
Seal Material EPDM
Seal Type Double O-Ring Stem
Color Gray
Max Pressure 150 PSI (10.3 bar) @ 70˚F (21˚C)
Carton Qty 1
UPC Code 0610377819503
Ratings & Standards NSF/ANSI 61
Installation Manual Hayward SB2050STE Installation Manual
Technical Data Hayward SB2050STE Technical Data
Dimensions Image Hayward SB2050STE Drawing
