1" Horizontal Flow Acrylic Flow Meter (5-35 GPM), F-30100P


Quick Overview

SKU: F-30100P



  • Model Variations:
    • F-300 = Horizontal flow
    • D-300 = Vertical down flow
    • U-300 = Vertical up flow
  • Well suited for closed pipe installations
  • Easy to read dual scale (GPM / LPM), screen printed on both sides of the meter body
  • Acceptable for outdoor installations (direct sunlight okay)
  • Pitot Tube (impact tube) design makes it easy to install on existing pipe
  • One piece, machined acrylic meter body, annealed for added strength and chemical resistance
  • Included SS clamps and gasket seal
  • Standard and Low Flow options available
  • For use on PVC or Copper Pipes (refer to literature)

Additional Information

SKU F-30100P
Manufacturer Blue White
Model Type Acrylic
Model Option Horizontal Flow
Model # F-300
Application Liquid
Pipe Type Schedule 40
Size 1"
Flow Range 5-35 GPM
Body Material Acrylic
O-Ring Material Neoprene
Float Material PTFE
Maximum PSI 75 PSI (5.17 bar) @ 70˚F (21˚C)
Maximum Temperature 190˚F / 88˚C @ 0 PSI
Accuarcy +/- 10%
Color Clear
Installation Manual Blue White F-30100P Installation Manual
Technical Data Blue White F-30100P Technical Data
