1-1/2" Hayward PR Series Piston PVC Pressure Regulator Valve w/Threaded ends
Main image
Click to view image in fullscreen


calcActive())">
SKU:
PR10150T
Color:
Gray
1-1/2" Hayward PR Series Piston PVC Pressure Regulator Valve w/Threaded ends, FPM O-rings
$1,999.99
Details
Piston style Pressure Regulator Valves are ideal for high viscosity fluids. Hayward Pressure Regulators prevent downstream pressure from exceeding a preset pressure. When the upstream pressure increases beyond the set pressure of the regulator, the regulator prevents the downstream pressure from exceeding the set pressure. Available in 1/4 inch to 1-1/2 inch sizes. PVC or CPVC, with threaded or flanged ends. Metric threads available upon request. Standard FPM Seals and can be set from 5 to 75 psi. EPDM Seals optional.
1-1/2" Hayward PR Series Piston PVC Pressure Regulator Valve w/Threaded ends, FPM O-rings
Additional Information
| MPN | PR10150T |
|---|---|
| Inventory Type | DS |
| Manufacturer | Hayward |
| Type | Pressure Regulator Valve |
| Style | Piston |
| Series | PR Series |
| Valve Type | Piston Pressure Regulator Valve |
| Valve Size | 1-1/2" |
| Valve Connection Type | Threaded |
| Material | PVC |
| Seal Type | Double O-Ring Stem |
| Seal Material | FPM |
| Max Pressure | 150 PSI (10.3 bar) @ 70˚F (21˚C) |
| Carton Qty | 1 |
| UPC Code | 0610377162029 |
| Color | Gray |
| Installation Manual | Hayward PR10150T Installation Manual |
| Technical Data | Hayward PR10150T Technical Data |
| Dimensions Image |
