PVC Duct Tees
Bidding a job & need contractor pricing?
We've got you covered!
PVC duct tees are three way pipe fittings used in ductwork systems to split or combine the direction of airflow between multiple pipes. PVC duct tees provide a junction point where a main duct line can be divided into two or more branches for the distribution or collection of gaseous media. They are made specifically for use in ductwork and ventilation systems to transport air, gasses, fumes, exhausts, and waste emissions that may contain odors, dust, or other particulates to a point of release or treatment. PVC duct tees are used to complete the design and installation of PVC ductwork in industrial ventilation systems, agricultural air handling systems, and HVAC systems used in residential, commercial, and public buildings. They are also used in laboratories and manufacturing facilities due to their chemical resistance and durability.
Our PVC duct tee fittings are USA made by Harrison Machine and Plastic under the trade name Harrison SUPERDUCT®, one of the nation’s top manufacturers and brands of thermoplastic ductwork. PVC ductwork and tee fittings are to be used with air and compatible gaseous media in open air, non-pressurized applications only. They are not for use in pressure systems, with liquids, or with known incompatible chemicals. Always verify chemical compatibility prior to use.
PVC Duct Tee Sizes and Options
PVC duct tee sizes range from 3″ to 24″ in Iron Pipe Size (IPS) diameter. Large diameter duct tee fittings up to 60″ are available on request. Reducing duct tees are available to connect ductwork of different sizes and range in options from 3″ x 3″ x 2″ up to 24″ x 24″ x 20″. Our full selection in sizing and ability to meet custom size requirements demonstrates our commitment to precision, performance, and project completion.
PVC duct tee fittings come with belled socket type connection joints. For installation, use a professional quality PVC cement and primer for a secure fit. For large duct fittings above 14″, hot air welding is recommended.
Technical Specifications
These duct tees are fabricated from industrial grade, premium quality PVC material that meets ASTM D1784 standards for high purity, consistency, and overall reliable performance.
- Material Profile: Type I Grade I PVC Cell Class 12454-B.
- Color: Dark gray.
- Performance Standards: Meets and/or exceeds ASTM D testing standards for ductwork applications.
- Pressure: For non-pressurized systems only.
- Temperature: Approved for up to 140°F (60°C).
- Sizing Standard: Schedule 40 / IPS thickness standard.
- Size Options: Range from 3″ to 24″, with large diameter ductwork up to 60″ on request.
- Connection Options: 3 way belled end sockets.
Features and Benefits
Harrison SUPERDUCT® PVC tee fittings are used for their chemical resistance to most fumes and gaseous media. The fittings are lightweight and high strength which makes for easier installation and a longer service life compared to metal ductwork.
- PVC Material: Heavy duty thermoplastic with excellent corrosion resistance, durability, and will not rust or degrade.
- Chemical Resistance: Resistant to many acids, alkalis, alcohols and their gasses, fumes, and vapors.
- Multiple Options: Standard 3 way duct tees or reducing duct tees in complete sizes to meet project needs
- Hard Working: Engineered for long term service and minimal maintenance to keep ductwork systems running.
- Airtight: Will provide a secure, long lasting seal when properly installed.
- Easy to Install: Lightweight and impact resistant for easy handling and installation.
Applications and Uses
Common applications include HVAC systems in residential, commercial, and public buildings, industrial and laboratory ventilation systems for controlling and removing hazardous fumes and gasses, medical and scientific research facilities, and agricultural operations for distributing air or removing dust and odors.
Harrison PVC SUPERDUCT® tee fittings are a leading choice in quality and performance, trusted by professionals for decades. They are precision engineered to deliver the reliable, long lasting service that ductwork systems require. Manufactured to the highest standards and from premium materials, our ductwork pipe supplies are made to exceed requirements. For more information or details on contractor pricing, contact us.
