2" Hayward TBB Series True Union CPVC Ball Valve

SKU: TBB2020FPFG
Color: Light Gray
2" Hayward TBB Series True Union CPVC Ball Valve w/ Flanged ends, FPM O-rings

Details

TBB Series true union ball valves are offered in PVC, CPVC, PP and PVDF. O-rings are FPM or EPDM. Up to 2 inch sizes have socket and threaded end connections. All seats are PTFE.

Additional Information

MPN TBB2020FPFG
Inventory Type DS
Manufacturer Hayward
Type Ball Valve
Style True Union
Series TBB Series
Valve Type True Union Ball Valve
Valve Size 2"
Valve Connection Type Flanged
Material CPVC
Seal Type Double O-Ring Stem
Seal Material FPM
Seat Material PTFE
Port Type Full
Max Pressure 225 PSI (10.3 bar) @ 70˚F (21˚C)
Carton Qty 12
UPC Code 0610377093231
Color Light Gray
Installation Manual
Technical Data
