3/4" Hayward CVH Series Profile2™ True Union CPVC Ball Valve
Main image
Click to view image in fullscreen
![]()
SKU:
CVH2075ASTV0A00
Color:
Light Gray
3/4" Hayward CVH Series Profile2™ True Union CPVC Ball Valve
$237.99
Details
Hayward's CVH Series Profile2™ with characterized ball for proportional flow configurations. Provides two linear flow curves – one for fast opening, one for slow opening. Slow opening shipped standard. Fast open on request. 1/4 inch - 2 inch rated @ 250PSI. Offered in PVC and CPVC. O-rings are FPM or EPDM and seats are PTFE. NSF/ANSI61 and NSF/ANSI372 Listed. Available in Actuation Ready configuration.
3/4" Hayward CVH Series Profile2™ True Union CPVC Ball Valve
Additional Information
| MPN | CVH2075ASTV0A00 |
|---|---|
| Inventory Type | DS |
| Manufacturer | Hayward |
| Type | Ball Valve |
| Style | True Union |
| Series | CVH Series Profile2™ |
| Manufacturer Warranty | 2 Year Warranty |
| Valve Type | True Union Ball Valve |
| Valve Size | 3/4" |
| Valve Connection Type | Socket and Threaded |
| Material | CPVC |
| Seal Type | Double O-Ring Stem |
| Seal Material | FPM |
| Seat Material | Reversible PTFE |
| Port Type | Full |
| Max Pressure | 250 PSI (17.2 bar) @ 70° F (21° C) |
| Carton Qty | 12 |
| UPC Code | 0610377353816 |
| Color | Light Gray |
| Ratings & Standards | NSF/ANSI 61 |
| Installation Manual | Hayward CVH2075ASTV0A00 Installation Manual |
| Technical Data | Hayward CVH2075ASTV0A00 Technical Data |
| Dimensions Image |
