3" Hayward Actuator Ready TW Series 3-Way True Union CPVC Ball Valve

SKU: HCTN2300FV
Color: Light Gray
3" Hayward Actuator Ready TW Series 3-Way True Union CPVC Ball Valve w/Flanged ends, FPM O-rings

Details

HCTN Series ready for actuation valves are the TW Series 3-way ball valves with the NT ball installed for actuated operation. The valve has no handle or mounting kit. In other words, it is ready for actuation. If ordered with an actuator a mounting kit is included at no charge. The mounting kit is determined by the choice or type of actuator. TW, TP, and CF balls are also available.

Additional Information

MPN HCTN2300FV
Inventory Type DS
Manufacturer Hayward
Type Ball Valve
Style 3-Way True Union
Series Actuator Ready TW Series
Valve Type True Union Ball Valve
Valve Size 3"
Valve Connection Type Flanged
Material CPVC
Seal Type Double O-Ring Stem
Seal Material FPM
Max Pressure 150 PSI (10.3 bar) @ 70˚F (21˚C)
Actuation Type Actuator Ready
Carton Qty 1
UPC Code 0610377833660
Color Light Gray
