4" Hayward YC Series CPVC Y-Check Valve w/Flanged ends, FPM O-rings
                Main image
                Click to view image in fullscreen

![]()





 calcActive())">








                        SKU:


                        YC20400F



                        Color:


                        Light Gray

                                                                                                        4" Hayward YC Series CPVC Y-Check Valve w/ Flanged ends, FPM O-rings






                        $2,359.99




                    Details
YC Series Y-check valves are offered in PVC and CPVC. O-rings are FPM standard but EPDM is available. All sizes are either socket, threaded or flanged body style. True union socket or threaded end connections are available. For spring-loaded Y-check valves, see the SLC Series. All valves are assembled with silicone free lubricant.
    4" Hayward YC Series CPVC Y-Check Valve w/ Flanged ends, FPM O-rings
    Additional Information
| MPN | YC20400F |
|---|---|
| Inventory Type | DS |
| Manufacturer | Hayward |
| Type | Check Valve |
| Style | Y |
| Series | YC Series |
| Valve Type | Check Valve |
| Valve Size | 4" |
| Valve Connection Type | Flanged |
| Material | CPVC |
| Seal Type | Double O-Ring Stem |
| Seal Material | FPM |
| Flow Design | Full |
| Max Pressure | 150 PSI (10.3 bar) @ 70˚F (21˚C) |
| Carton Qty | 1 |
| UPC Code | 0610377226455 |
| Color | Light Gray |
| Installation Manual | Hayward YC20400F Installation Manual |
| Technical Data | Hayward YC20400F Technical Data |
| Dimensions Image |
