4" Hayward Actuator Ready TBH-Z Series True Union PVC Ball Valve
Main image
Click to view image in fullscreen
calcActive())">
SKU:
TBH1400A0SVKZ00
Color:
Gray
4" Hayward Actuator Ready TBH-Z Series True Union PVC Ball Valve
$580.99
Details
Hayward's TBH-Z Series (Z-Ball) true union ball valves have a drilled ball to vent gases for sodium hypochlorite service. Available in PVC or CPVC materials with FPM o-rings only and PTFE seats. Sizes are 1/2" to 2" with IPS or DIN/EN socket, threaded and flanged end connections.
All valves are assembled with silicone free lubricant. Assisting users in protecting property and life, a standard integral lock-out feature secures onto the body of the valve. Actuator ready design with ISO 5211 pattern – available on all sizes. Fully pressure rated for 250 PSI / PN16 at 70°F/23°C non-shock across all sizes and materials. Full 250 PSI / PN16 Rating, Non-Shock at 70°F / 23°C
Additional Information
MPN | TBH1400A0SVKZ00 |
---|---|
Inventory Type | DS |
Manufacturer | Hayward |
Type | Ball Valve |
Style | True Union |
Series | Actuator Ready TBH "Z-Ball" Series |
Manufacturer Warranty | 2 Year Warranty |
Valve Type | True Union Ball Valve |
Valve Size | 4" |
Valve Connection Type | Socket |
Material | PVC |
Seal Type | Double O-Ring Stem |
Seal Material | FPM |
Seat Material | Reversible PTFE |
Max Pressure | 250 PSI (17.2 bar) @ 70° F (21° C) |
Carton Qty | 1 |
Color | Gray |
Ratings & Standards | NSF/ANSI 61 |
Installation Manual | Hayward TBH1400A0SVKZ00 Installation Manual |
Technical Data | Hayward TBH1400A0SVKZ00 Technical Data |
