1-1/2" Hayward TC Series True Union PVC Check Valve

SKU: TC10150F

1-1/2" Hayward TC Series True Union PVC Check Valve w/ Flanged ends, FPM O-rings

TC Series true union ball check valves are offered in PVC, CPVC, and PP. O-rings and seats are FPM or EPDM. 1/4 inch and 3/8 inch sizes are PVC only and are trim check design. They have socket or threaded end connections. Others up to 2 inch sizes have socket and threaded end connections. All valves are assembled with silicone free lubricant.

SKU TC10150F
Manufacturer Hayward
Type Check Valve
Style True Union
Series TC Series
Valve Type True Union Ball Check Valve
Valve Size 1-1/2"
Valve Connection Type Flanged
Material PVC
Seal Type Double O-Ring Stem
Seal Material FPM
Flow Design Full
Color Gray
Max Pressure 235 PSI (10.3 bar) @ 70˚F (21˚C)
Carton Qty 1
UPC Code 0610377166355
Ratings & Standards NSF/ANSI 61
Installation Manual Hayward TC10150F Installation Manual
Technical Data Hayward TC10150F Technical Data
Dimensions Image Hayward TC10150F Drawing
