1/4" OBS-V Series Polypropylene Pressure Gauge, Bottom Mount, -30-30 PSI
Main image
Click to view image in fullscreen
![]()
SKU:
OBS-V-PP
2-1/2" Truflo OBS-V Series Gauge Only Polypropylene Pressure Gauge, 1/4" 316SS Bottom Mount, -30-30PSI, Glycerin Filled
$71.00
Details
Features:
- Suitable for Corrosive Environments
- Large 2-1/2"
- -30 – +30 psi Range
- 3 Range Tabs | Red | Yellow | Green
- High Accuracy | +/-0.75%
- Factory Pre-Filled
- High Impact Case Housing
Applications:
- Chemicals | Acids | Bases
- Process Pressure
- Strainer Clean-Out Notification
- Filter Bag Replacement Notification
- Pressure Leak Detection
2-1/2" Truflo OBS-V Series Gauge Only Polypropylene Pressure Gauge, 1/4" 316SS Bottom Mount, -30-30PSI, Glycerin Filled
Additional Information
| MPN | OBS-V-PP |
|---|---|
| Inventory Type | DS |
| Manufacturer | Icon Process Controls |
| Type | Pressure Gauge |
| Style | Bottom Mount |
| Series | OBS-V Series |
| Gauge Size | 2-1/2" |
| Gauge Connection Type | MPT |
| Material | Polypropylene |
| Max Pressure | 30 PSI |
| Working Pressure | -30 PSI |
| Maximum Temperature | 190° F (88° C) |
| Accuracy | +/- 0.75% |
| Installation Manual | |
| Technical Data |
