1/2" Hayward TBB Series True Union CPVC Ball Valve

SKU: TBB2005FPEG

1/2" Hayward TBB Series True Union CPVC Ball Valve w/ Flanged ends, EPDM O-rings
$69.99
-
+
OR

TBB Series true union ball valves are offered in PVC, CPVC, PP and PVDF. O-rings are FPM or EPDM. Up to 2 inch sizes have socket and threaded end connections. All seats are PTFE.

SKU TBB2005FPEG
Manufacturer Hayward
Type Ball Valve
Style True Union
Series TBB Series
Valve Type True Union Ball Valve
Valve Size 1/2"
Valve Connection Type Flanged
Material CPVC
Seal Type Double O-Ring Stem
Seal Material EPDM
Seat Material PTFE
Port Type Full
Color Light Gray
Max Pressure 225 PSI (10.3 bar) @ 70˚F (21˚C)
Carton Qty 48
UPC Code 0610377093101
Installation Manual Hayward TBB2005FPEG Installation Manual
Technical Data Hayward TBB2005FPEG Technical Data
