0-15' Hayward HLS Series CPVC Advanced Submersible Pressure Level Sensor
Details
Hayward's HLS Series level sensor employs advanced sensor technology to ensure highly accurate and repeatable measurements in a wide range of corrosive liquid applications.
| Specifications: | |
| Standard Cable Length | 30 feet |
| Cable | Vented, 4 conductor, FEP cover |
| Temperature Effects | +/- 1.5% TEB (Total Error Band = linearity + hysteresis + repeatability + zero and span settings + temperature effects) |
| Power Requirement | 10-35 VDC |
| Output Signal | 4-20 mA, scaled for full sensor range |
Additional Information
| MPN | HLS211F000 |
|---|---|
| Inventory Type | DS |
| Manufacturer | Hayward |
| Type | Level Sensor |
| Series | HLS Series |
| Material | CPVC |
| Seal Material | FPM |
| Max Pressure | 6.5 PSI |
| Maximum Temperature | 140° F (60° C) |
| Carton Qty | 1 |
| Manufacturer Warranty | 2 Year Warranty |
| Color | Light Gray |
| Accuracy | +/- 0.25% |
| Ratings & Standards | ASTM D1784 |
| Technical Data | Hayward HLS211F000 Technical Data |
| Dimensions | 5.8" L x 1.25" Diameter |
