1" Hayward TC Series True Union CPVC Check Valve


1" Hayward TC Series True Union CPVC Check Valve w/ Socket and Threaded ends, EPDM O-rings

TC Series true union ball check valves are offered in PVC, CPVC, and PP. O-rings and seats are FPM or EPDM. 1/4 inch and 3/8 inch sizes are PVC only and are trim check design. They have socket or threaded end connections. Others up to 2 inch sizes have socket and threaded end connections. All valves are assembled with silicone free lubricant.

Manufacturer Hayward
Type Check Valve
Style True Union
Series TC Series
Valve Type True Union Ball Check Valve
Valve Size 1"
Valve Connection Type Socket and Threaded
Material CPVC
Seal Type Double O-Ring Stem
Seal Material EPDM
Flow Design Full
Color Light Gray
Carton Qty 12
UPC Code 0610377687171
Ratings & Standards NSF/ANSI 61
Installation Manual Hayward TC20100STE Installation Manual
Technical Data Hayward TC20100STE Technical Data
Dimensions Image Hayward TC20100STE Drawing
