2-1/2" Hayward BYV Series PVC Butterfly Valve, ECP Series Actuated

SKU: ECPBYV11025V
Color: Gray
2-1/2" Hayward BYV Series PVC Butterfly Valve, w/GFPP ECP Series Actuator Installed

Details

The BYV Series butterfly valves are available in PVC, CPVC and GFPP bodies and discs. Liners and seals available in Viton, EPDM or Nitrile materials. 316SS Stems are standard. The BYV Series features a revolutionary hand lever design which features a 72 spline interlock mechanism allowing for 19 stopping positions every 5 degrees. Additionally, the hand lever material incorporates a UV inhibitor for enhanced performance in outdoor applications.

Additional Information

MPN ECPBYV11025V
Inventory Type DS
Manufacturer Hayward
Type Butterfly Valve
Style ECP Series Actuated
Series BYV Series
Valve Size 2-1/2"
Material PVC
Disc Material PVC
Seal Material FPM
Max Pressure 150 PSI (10.3 bar) @ 70˚F (21˚C)
Carton Qty 1
UPC Code 0610377349185
Color Gray
Ratings & Standards NSF/ANSI 61
Installation Manual
Technical Data
