2" MPT Paddlewheel Flow Meter with Molded In-Line Body (20-200 GPM), TB-200MI-GPM4

SKU: TB-200MI-GPM4

TOTAL ONLY

Regular Price: $449.99

Special Price $429.99

-
+
OR
BW Digi-Meter® F-1000 Features:
  • Easy to read 6 digit LCD, up to 4 decimal positions.
  • Tamper proof.
  • Battery operated (2 AAA batteries included)
  • Total reset function can be disabled.
  • Display update time: Rate 1.5 sec., Total 0.5 sec.
  • Factory calibrated - nothing to program.
  • Custom calibration units available. Contact the factory.
  • Weather resistant ABS enclosure. NEMA 4X.
  • LCD is not recommended for direct sunlight applications.

3 model variations:
  • RB = Rate Only
  • TB = Total Only
  • RT = Rate & Totalizer
SKU TB-200MI-GPM4
Manufacturer Blue White
Model Number TB - Total Only
Series F-1000
Flow Meter Size Summary 2" MPT
Flow Meter Body Material Polypropylene
Flow Meter O-Ring Material Viton
Material PVDF
Color Black
Max Pressure 300 psig (20 bar) @ 70° F (21° C)
Maximum Temperature 200° F (93° C) @ 0 PSI
Flow Range 20-200 GPM
Accuracy +/- 2%
Application State Liquid
Installation Manual Blue White TB-200MI-GPM4 Installation Manual
Technical Data Blue White TB-200MI-GPM4 Technical Data
Dimensions Image TB-200MI-GPM4
Dimensions
A 6-3/8"
B 6-3/4"
