1/2" MPT Panel Mount Polysulfone Flow Meter (.02-.25 GPM), F-44250LE-8
Main image
Click to view image in fullscreen
![]()
Details
- Tough Polysulfone meter body resists high temperatures and pressures
- Compact size for tight installation spaces
- 2” scale length
- In-line or panel mount configurations available (for vertical installation)
- Optional integral flow adjustment valve
- Standard Models: 316 SS guide rod
- K-Series: Hastelloy C guide rod (for corrosive environments)
- Optional: SolarMeter® Brass Adapters
Additional Information
| MPN | F-44250LE-8 |
|---|---|
| Inventory Type | DS |
| Manufacturer | Blue White |
| Model Number | F-440 |
| Flow Meter Size Summary | 1/2" MPT |
| Flow Meter Body Material | Polysulfone |
| Flow Meter O-Ring Material | Viton (Optional EP) |
| Flow Meter Adapter Material | Polysulfone |
| Flow Meter Guide Rod Holder Material | Polysulfone |
| Guide Rod Material | 316 SS |
| Flow Meter Float Material | PVDF |
| Material | Polysulfone |
| Max Pressure | 175 PSI (12.0 bar) @ 70° F (21° C) |
| Maximum Temperature | 212° F (100° C) @ 0 PSI |
| Flow Range | .02-.25 GPM |
| Color | Clear |
| Accuracy | +/- 4% |
| Application State | Liquid |
| Installation Manual | |
| Technical Data |
