1" MPT Acrylic Flow Meter (1-15 GPM), F-55015L

SKU: F-55015L

Regular Price: $199.99

Special Price $149.99

  • Durable, highly polished, one piece meter body.
  • Annealed for added strength and chemical resistance.
  • Acceptable for outdoor installations (acceptable in direct sunlight)
  • Bulkhead nuts attach directly to inside panel.
  • Optional adjustable flow control: needle-type adjustment valve.
  • Direct reading permanent scale.
  • White back reflector for easy reading.
  • 316 stainless, PTFE or Hastelloy floats and float guides.

Adapter Options:

  • 1/4″, 3/8″, 3/4″, 1″ Male NPT
  • 1/2″ Hose Barb
SKU F-55015L
MPN F-55015L
Inventory Type DS
Manufacturer Blue White
Model Number F-550
Flow Meter Size Summary 1" MPT
Flow Meter Body Material Acrylic
Flow Meter O-Ring Material Viton (Optional EP)
Flow Meter Adapter Material Polypropylene
Guide Rod Material 316 SSS
Flow Meter Float Material 316 SSS
Material Acrylic
Color Clear
Max Pressure 250 PSI (17.2 bar) @ 70° F (21° C)
Maximum Temperature 200° F (93° C) @ 0 PSI
Flow Range 1-15 GPM
Accuracy +/- 5%
Application State Liquid
Installation Manual Blue White F-55015L Installation Manual
Technical Data Blue White F-55015L Technical Data
