3/8" MPT Adjustable Acrylic Flow Meter (.1-1 GPM), F-55375LA
Main image
Click to view image in fullscreen
calcActive())">
Details
- Durable, highly polished, one piece meter body.
- Annealed for added strength and chemical resistance.
- Acceptable for outdoor installations (acceptable in direct sunlight)
- Bulkhead nuts attach directly to inside panel.
- Optional adjustable flow control: needle-type adjustment valve.
- Direct reading permanent scale.
- White back reflector for easy reading.
- 316 stainless, PTFE or Hastelloy floats and float guides.
Adapter Options:
- 1/4?, 3/8?, 3/4?, 1? Male NPT
- 1/2? Hose Barb
Additional Information
MPN | F-55375LA |
---|---|
Inventory Type | DS |
Manufacturer | Blue White |
Model Number | F-550A |
Flow Meter Size Summary | 3/8" MPT |
Flow Meter Body Material | Acrylic |
Flow Meter O-Ring Material | Viton (Optional EP) |
Flow Meter Adapter Material | Polypropylene |
Guide Rod Material | 316 SSS |
Flow Meter Float Material | 316 SSS |
Material | Acrylic |
Max Pressure | 250 PSI (17.2 bar) @ 70° F (21° C) |
Maximum Temperature | 200° F (93° C) @ 0 PSI |
Flow Range | .1-1 GPM |
Color | Clear |
Accuracy | +/- 5% |
Application State | Liquid |
Installation Manual | |
Technical Data |
