110MM Horizontal Flow Acrylic Flow Meter (600-1800 LPM), F-30110M

SKU: F-30110M

Regular Price: $150.24

Special Price $125.99

  • Model Variations:
    • F-300 = Horizontal flow
    • D-300 = Vertical down flow
    • U-300 = Vertical up flow
  • Well suited for closed pipe installations
  • Easy to read dual scale (GPM / LPM), screen printed on both sides of the meter body
  • Acceptable for outdoor installations (direct sunlight okay)
  • Pitot Tube (impact tube) design makes it easy to install on existing pipe
  • One piece, machined acrylic meter body, annealed for added strength and chemical resistance
  • Included SS clamps and gasket seal
  • Standard and Low Flow options available
  • For use on PVC or Copper Pipes (refer to literature)
SKU F-30110M
Inventory Type DS
Manufacturer Blue White
Model Number F-300
Flow Meter Size Summary 110MM
Flow Meter Body Material Acrylic
Flow Meter O-Ring Material Neoprene
Flow Meter Float Material 316 SS
Material Acrylic
Color Clear
Max Pressure 75 PSI (5.17 bar) @ 70˚F (21˚C)
Maximum Temperature 190˚F (88˚C) @ 0 PSI
Flow Range 600-1800 LPM
Accuracy +/- 10%
Application State Liquid
Application Pipe Type PN10
Installation Manual Blue White F-30110M Installation Manual
Technical Data Blue White F-30110M Technical Data
