Kynar PVDF Pipe & Valve Specifications

PVDF Pipe Measurements, Thickness and Weight

Finding the right size pipe for the job can sometimes be difficult as well as trying to compare measurements between the available pipe sizes. To make this process easier, we have compiled our PVDF piping measurements in terms of size, wall thickness, inner diameter, outer diameter and pipe weight in pounds per foot. Review the following table for Schedule 80 PVDF Kynar specifications:

Size (in.)

Wall Thickness (in.)

Inner Diameter (in.)

Outer Diameter (in.)

Weight / Foot (lbs/ft.)

1/4

0.119

0.25

0.54

0.128

3/8

0.126

0.375

0.675

0.178

1/2

0.147

0.500

0.840

0.226

3/4

0.154

0.750

1.050

0.353

1

0.179

1.000

1.315

0.518

1 1/2

0.200

1.500

1.900

0.868

2

0.218

2.000

2.375

1.190

3

0.300

3.000

3.500

2.450

4

0.337

4.000

4.500

3.580

6

0.432

6.000

6.625

6.730

8

0.500

8.000

8.625

10.39

10

0.593

10.00

10.75

15.39

12

0.687

12.00

12.75

26.11

For More PVDF Info

Visit our PVDF Kynar piping product page for details on PVDF pipe, characteristics, design codes, standards and common applications. Review our PVDF technical specifications brochure for extended manufacturer specifications, physical, mechanical and thermal performance characteristics or read our PVDF vs PVC, CPVC and Metal overview to compare PVDF against these other commonly used piping materials.
